Description
MAIN FEATURES:
-Exceptionally easy system setup via an LCD user interface.
-Open-nut drive system and rugged die-cast aluminum construction for reliable operation.
-Supports inward- and outward-opening gates without needing mechanical end-stops.
-Automated limit setup for double and single swing gates.
-Fail-safe optoelectronic position and collision detection system ensures maximum safety.
-Advanced closed-loop speed control for safe and reliable operation, even on inc lined gates under windy conditions.
-Multiple operating features including Intruder-detection Alarm Modes (a world first).
-Onboard CENTURION code-hopping multichannel receiver with selective add and delete.
-Battery backup for uninterrupted operation during power failures.
DESCRIPTION
Input Voltage 90V – 240V AC +/- 10%, 50/60Hz [*]
Motor Voltage 12V DC
Motor Power Supply Battery-driven [**] 1.8A Charger
Push Force – Max 250kgf
Typical Gate Opening Time 11 sec
Duty Cycle – Mains Present 50% [***]
Daily Operations – Max 250
Maximum Leaf Width for Corresponding Gate Mass (90° opening) <1.5m = 600kg <2m = 335kg ,2.5m = 215kg <3m = 150kg
Onboard Receiver Specification CENTURION code-hopping, multichannel, 433MHz, Capacity - 64 Transmitter Buttons
[*] – Can operate off a solar supply. [**] – 7Ah battery (can be upgraded for longer power failure autonomy). [***] – Based on 25°c ambient temperature and unit not in direct sunlight.
