Description
MAIN FEATURES:
-Main Features.
-Battery backup.
-Strong lifting capability.
-Whisper-quiet operation.
-Anti-crushing protection.
-Quick and easy installation.
-Wall-mounted controller with Courtesy Light.
-Onboard multichannel code-hopping receiver: – Open/close garage door. – Switch Courtesy Light on and off. – Override -automatic closing. – Electronically lock the system for added security.
-Compatible with CENTURION infrared safety beams.
RDO II TECHNICAL DATA:
DESCRIPTION
Input Voltage 220 – 240V +/- 10%, 50Hz [*]
Motor Voltage 24V DC
Motor Power Supply Battery-driven [**] – 200mA Charger – Peak
Opener Lifting Force 30kgf
Door Travel Speed 100 – 150mm/sec
Duty Cycle – Mains Present [***] 20% [****]
Daily Operations – Max 20
Maximum Door Size 6m² – (max width 2.8m)
Onboard Receiver Specification CENTURION code-hopping, 433MHz, capacity – 36 transmitter buttons [*****]
[*] – Can operate off a solar supply, consult Centurion Systems for assistance. [**] – 2 x 1.2A/H batteries (can be upgraded for longer power failure autonomy). [***] – Based on a pull force of less than 50% of rated. [****] – Based on 25°c ambient temperature. [*****] – Only 1 button per transmitter is used.
