Description
MAIN FEATURES:
-Very fast detection speed for quick response times.
-Detection filter and high-level circuit and loop protection provide excellent immunity to interference from external -sources for improved reliability.
-Easy to install and commission saving you time and money.
-Audible and visual diagnostics for ease of set up and maintenance.
-Removable terminals for quick and easy maintenance.
-Boot-loader interface for ease of firmware upgrades.
-Dedicated reset button to assist with quick maintenance procedures.
Wide, adaptive self-tuning range for outstanding reliability.
-Excellent, strong loop field strength for reliable operation.
-Selectable Permanent Presence feature to prevent unintended barrier or gate closure.
-Automatic Sensitivity Boost feature which boosts the sensitivity automatically for the reliable detection of vehicles of various heights.
-Compact housing with clever design features enhancing ease of installation and monitoring diagnostics.
FLUX SA TECHNICAL DATA:
DESCRIPTION
Operating Voltage 10 – 40V DC, or 7 – 28V AC
Standby Current 50mA
Output Relay Rating 1A @ 125V AC
Detection Time 4ms @ 100kHz loop frequency 10ms @ 40kHz loop frequency
Visual LED Indicators Showing Power; Loop Fault; Loop detection level (five LED’s); Detect
Audible Indicators Buzzer with indication of loop detection level and loop fault
Weight 92g
Detector Tuning Range 15 – 1500μH
Electronics Protection Insolation transformer with 10kA lightning protection
Dimensions 105mm (length) X 60mm (width) X 26mm (height)
